Swing Reduction 24100J11091F3 24100J11091F5 24100J11091F7 Fit Excavator Kobelco SK200LC-3 SK200LC Mark III

Product Name: Swing Reduction Gearbox Assy
Reference Part Number: 24100J11091F3, 24100J11091F5, 24100J11091F7
Compatible Machine: Excavator Kobelco SK200-3 SK200LC-3 SK200 Mark III

Pos. Part No Qty Parts name Comments
5. R25P0047D8 [1] BEARING KOB ROLLER
6. 25Z494D11 [1] BEARING KOB ROLLER
9. 2410T340 [4] ROLLER SHAFT KOB
10. 2401N468 [1] RING GEAR KOB
11. 2401P1276 [1] SUN GEAR KOB
12. 2401P1277 [4] PINION KOB
13. 2401P1279 [4] KIT KOB , Serial Range: YQ01701–YQ01840 Superseded by part number: 24001T71F2
15. ZS23C08030 [12] SCREW,Hex Socket Head, M8 x 30mm KOB M08x1.25x30mm Superseded by part number: ZS28C08030
18. 2418P20198D3 [2] SPACER KOB (4)
19. 2401P1278 [1] SUN GEAR KOB , Serial Range: YQ01701–YQ01840 Superseded by part number: 2401P1434
20. ZR16X04500 [1] RING KOB Retaining — ID 45 x OD 58 x Th 1.8mm
23. 2425T383 [76] PLUG WRENCH NEEDLE,ROLLER, Serial Range: YQ01701–YQ01840 PLUG WRENCH NEEDLE,ROLLER,24. 2425T384 [140] NEEDLE BEARING KOB ROLLER
25. ZR16X08500 [1] LOCKING RING KOB SNAP
26. ZS83C20020 [2] SCREW KOB Set — M20x2.50x20mm
28. 2420T6698D3 [1] RIGID TUBE KOB
29. ZG31U12000 [1] ELBOW KOB 90°
30. ZE82T12000 [1] PLUG KOB 3/4″ PT
33. ZS23C14140 [10] SCREW,Hex Socket Head, M14 x 140mm KOB M14x2.0x140mm
34. ZR16X04000 [4] RING KOB Retaining — ID 37 x OD 40 x Th 1.8mm
37. 2410N519 [1] FINGER ASSY. KOB
38. 2418P23538 [1] HOSE KOB
39. ZD11P09500 [1] O-RING KOB ID 94.6 ± 0.81 x OD 105mm
40. 2418R259 [1] OIL SEAL KOB
41. 2418R2D60 [1] SNAP RING KOB SNAP
42. 2418T21667 [1] PLATE KOB
43. 2418T20987 [1] PLATE KOB
44. 2418T20986 [1] PLATE KOB
45. 2418P22799 [1] RETAINER KOB
46. 2418T20988 [1] SPACER KOB (4)
47. 2414J2298 [1] HOUSING KOB
48. 2418T20989 [1] SPACER KOB
49. 2413J381 [1] DIFF. SPIDER KOB SPIDER
50. ZP26D08025 [4] PIN KOB Roll — OD 08 x 25mm Long
51. 2418T20963 [8] THRUST WASHER KOB , Serial Range: YQ01701–YQ01840 Superseded by part number: 2418T25314
52. 2413N462F1 [1] SPIDER KOB
53. 2418T20962 [4] THRUST WASHER KOB
54. 2418T19775D3 [4] THRUST WASHER KOB
56. 2441U819F2 [1] HYDRAULIC MOTOR KOB MOTOR. SWING, Serial Range: YQ01841–YQ01868 Superseded by part number: 2441U819F3
56-2. 2441U804F1 [1] HYDRAULIC MOTOR KOB MOTOR SEE(C P M)
56-3. 2436U1283F1 [1] VALVE PRESSURE RELIE KOB REDUCTION SEE(C. P. M)
56-5. ZD12G03500 [2] O-RING,34.40mm ID x 40.60mm OD x 3.10mm KOB ID 34.40 ± 0.33 x OD 40mm
56-6. 2436U1431F4 [1] CONTROL VALVE KOB VALVE. CONTROL SEE(C .P. M) Superseded by part number: 2436U1431F6
57. 2401P1434 [1] SUN GEAR KOB , Start Serial: YQ01841-
58. 2401P1438 [4] PINION KOB , Serial Range: YQ01841–YQ01848 Superseded by part number: 2401P1440
59. 2425R332 [4] NEEDLE BEARING KOB , Start Serial: YQ01841-
60. 2418T24791 [8] RING KOB THRUST WASHER, Serial Range: YQ01841–YQ01848
61. 2441U819F3 [1] HYDRAULIC MOTOR KOB MOTOR. SWING, Start Serial: YQ01867-
61-2. 2441U804F1 [1] HYDRAULIC MOTOR KOB MOTOR SEE(C. P. M)
61-3. 2436U1283F1 [1] VALVE PRESSURE RELIE KOB VALVE SEE(C P M)
61-4. ZS23C12135 [6] SCREW,Hex Socket Head, M12 x 135mm KOB M12x1.75x135mm
61-5. ZD12G03500 [2] O-RING,34.40mm ID x 40.60mm OD x 3.10mm KOB ID 34.40 ± 0.33 x OD 40mm
61-7. 2436U1431F6 [1] CONTROL VALVE KOB VALVE. CONTROL SEE(C P M)
62. 2418T25314 [8] THRUST WASHER KOB , Start Serial: YQ01848
63. 2401P1440 [4] PINION KOB , Start Serial: YQ01848
70. 2418T23087 [1] SPACER
71. 2418T5028 [1] PLATE COVER PLATE COVER
