Modulating Valve Assembly 244-3114 Fit Caterpillar Tractor 623K 621K 637K, Wheel Loader 924G 924H 928H 930G 962G 966G 966H 972K 980M 988H

Product Name: MDL Valve Group
Reference Part Number: 244-3114, 2443114
Compatible Machine: Caterpillar Tractor 623K 621K 637K D10R D10T D5M D5N D6M D6N D6R D6T D7R D8T D9T, Wheel Loader 924G 928H 930G 938G 938H 950G 950K 962G 962K 966G 966K 972G 972M 980H 980K 980M 982M 986H 988G 988H 988K 994H…

Description:
The modulating valve assemblies control clutch oil pressure.

Attributes:
• Integrated 2 Pin DT connector
• 2 bolt mount
• Assembly consists of valve, quick disconnect adapter, coil assembly, nut, washer, STOR o-ring seal.

Pos. Part No Qty Parts name Comments
1. 4F-4097 [1] SEAL-O-RING
2. 6D-7889 [7] SEAL-O-RING
3. 148-1928 [1] VALVE-RELIEF (TRANSMISSION)
4. 174-9603 [3] PLATE
5. 9X-4609 [1] SEAL-O-RING
6. 193-9131 [1] BRACKET AS
7. 234-5013 Y [1] SENSOR GP TEMPERATURE (HYDRAULIC OIL)
8. 244-3114 Y [6] VALVE GP MODULATING (24-VOLT)
9. 372-3328 [6] SLEEVE
10. 421-7214 Y [1] HARNESS AS TRANSMISSION
11. 368-8587 [1] TUBE AS
12. 368-8588 [1] TUBE AS
13. 421-8199 Y [1] VALVE GP SOLENOID (RELIEF)
14. 371-5157 [1] TUBE AS
15. 372-6146 [1] TUBE AS
16. 384-3753 [1] BODY
17. 392-9883 [7] PLATE-ORIFICE
18. 395-3194 [1] TUBE AS
19. 130-5300 [2] CLIP
20. 132-5789 [4] CLIP (LADDER)
21. 148-8336 [1] CONNECTOR AS
3J-1907 [1] SEAL-O-RING
6V-8397 [1] SEAL-O-RING
6V-8636 [1] CONNECTOR
22. 148-8362 [1] ELBOW AS
3D-2824 [1] SEAL-O-RING
5K-9090 [1] SEAL-O-RING
8T-6684 [1] ELBOW
23. 150-3028 [1] ELBOW AS
3D-2824 [1] SEAL-O-RING
6V-8397 [1] SEAL-O-RING
6V-9343 [1] ELBOW
24. 183-3399 [1] CONNECTOR AS
6V-8636 [1] CONNECTOR
214-7568 [1] SEAL-O-RING
228-7089 [1] SEAL-O-RING
25. 1S-0724 [1] CLIP
26. 204-8000 [1] MOUNTING CABLE TIE
28. 250-1424 [3] ELBOW AS
(EACH INCLUDES
214-7568 [1] SEAL-O-RING
228-7089 [1] SEAL-O-RING
29. 269-7852 [6] SEAL-O-RING
30. 307-2673 [1] PLUG AS
9S-8005 [1] PLUG (3/4-16-THD)
238-5080 [1] SEAL-O-RING
31. 309-5131 [1] PLUG AS
9S-8006 [1] PLUG (7/8-14-THD)
238-5081 [1] SEAL-O-RING
32. 319-6219 [1] ELBOW AS
6V-9005 [1] ELBOW
228-7093 [1] SEAL-O-RING
238-5084 [1] SEAL-O-RING
33. 319-6220 [2] ELBOW AS
(EACH INCLUDES)
6V-9008 [1] ELBOW
228-7093 [1] SEAL-O-RING
238-5084 [1] SEAL-O-RING
