Final Drive Travel Ring Gear XKAH-00904 Fit Excavator Hyundai R110-7 R110-7A R210LC-7 R210LC-7A R250LC-7

Product Name: Gear Ring
Reference Part Number: XKAH-00904, XKAH-01672
Compatible Machine: Excavator Hyundai R110-7 R110-7A R140-7 R140LC-7A R180LC-7 R210LC-7 R210LC-7A R210LC-7H R250LC-7 R250LC-7A RC215C-7…

Description:
The Internal Steel Ring Gear serves to securely attach the final drive gear to the hub, ensuring efficient power transmission, which is commonly used in planetary gear sets of final drives.

Pos. Part No Qty Parts name Comments
*-4. XKAH-00901 [1] REDUCTION GEAR ASSY
*-4. XKAH-01627 [1] REDUCTION GEAR ASSY
*-41. XKAH-00902 [1] HUB ASSY
*-41. XKAH-01670 [1] HUB ASSY
N1. XKAH-00451 [1] HUB
N1. XKAH-01671 [1] HUB
4. XKAH-00904 [1] RING GEAR(A)
4. XKAH-01672 [1] RING GEAR(A)
27. XKAH-00431 [10] PIN-PARALLEL
*-42. XKAH-00905 [1] SPINDLE ASSY
N2. XKAH-01033 [1] SPINDLE
8. XKAH-00907 [1] COUPLING GEAR
35. XKAH-00428 [10] BOLT-SOCKET
17. XKAH-00437 [10] PIN
*-43. XKAH-00908 [1] CARRIER ASSY
3. XKAH-00909 [1] CARRIER
6. XKAH-00910 [3] CLUSTER GEAR
6. XKAH-01673 [3] CLUSTER GEAR
9. XKAH-00911 [3] SHAFT
14. XKAH-00912 [6] COLLAR-THRUST
25. XKAH-00913 [6] BEARING-NEEDLE
5. XKAH-00914 [1] RING GEAR(B)
7. XKAH-00445 [1] GEAR-SUN
12. XKAH-00442 [1] PIECE-DISTENCE
13. XKAH-01034 [1] COVER
13. XKAH-01674 [1] COVER
15. XKAH-00439 [1] RING
19. XKAH-00022 [1] COUPLING
20. XKAH-00436 [2] PLATE-THRUST
23. XKAH-00435 [1] SEAL-RING
24. XKAH-00434 [2] BEARING-BALL
26. XKAH-00916 [2] SEAL-FLOATING
26. XKAH-01675 [2] SEAL-FLOATING
29. XKAH-00028 [1] O-RING
30. XKAH-00338 [3] PLUG-PT
30. XKAH-00032 [3] PLUG-PF
32. XKAH-00430 [20] BOLT-HEX
32. XKAH-01676 [20] SOKET BOLT
33. XKAH-00336 [20] WASHER-SPRING
34. XKAH-00429 [3] PIN-PARALLEL
36. XKAH-00033 [1] BALL-STEEL
38. XKAH-00035 [3] O-RING
39. XKAH-00194 [2] O-RING
40. XKAH-00427 [1] O-RING
K. XKAH-01054 [1] SEAL KIT SEE ILLUST
N. @ [AR] NOT
